HT Ductless Fume Hood
HT Ductless Fume Hood
The HT Ductless Fume Hood is designed to provide better safety protection for
laboratory personnel and the environment against toxic smoke, corrosive gases, and
other harmful substances. Unlike traditional fume hoods, the clean air fume hood uses
negative pressure technology to contain pollutants within the hood, preventing them
from escaping. It then passes chemical fumes or pollutants through an activated
carbon filter and circulates clean, safe air back into the laboratory, reducing
ventilation costs and energy consumption while protecting both personnel and the
environment. This equipment does not require external exhaust piping, making it
widely used in basic education, life sciences, forensic identification, clinical medicine,
and industrial clean applications. Due to its easy installation and energy-saving design,
it is gradually replacing traditional fume hoods.
Product Features:
- Utilizes fluid dynamics design to improve airflow uniformity, avoidingturbulence and enhancing safety while reducing noise and saving energy.
- Counterweight-style sliding front door, adjustable in height and position.
- The built-in lighting system provides optimal illumination angles and brightness, reducing visual fatigue. The detachable stand is easy to transport, lowering transportation costs.
- Uses internationally advanced activated carbon filtration technology to effectively filter harmful gases and substances without requiring an external exhaust system, reducing installation and indoor ventilation costs. The independent clean air equipment is portable.
- Optional HEPA high-efficiency filters can trap and filter particles generated during operation and recirculate clean air into the laboratory, meeting laboratory purification standards.
- Ergonomically designed front with a 10-degree tilt for more comfortable operation. The work surface is made of corrosion-resistant SUS304 stainless steel, and the sides are equipped with tempered glass observation windows, which are easy to clean.
- Integrated LCD display shows real-time parameters such as lighting, sterilization, and airflow. It features a sterilization and lighting interlock function to protect operators from UV light burns. The fan speed is adjustable in multiple levels, allowing users to set the appropriate airflow. It also has a differential pressure sensor and filter failure indicator function (optional).
- The work area is equipped with a UV sterilization lamp and includes two standard power outlets for convenient access during experiments.
