Kenton XYZ Platelet Agitator maintain thawed platelets at 22°C-24°C with continuous horizontal oscillation, ensuring safe storage before transfusion. Designed for medical facilities, these specialized units provide stable motion and temperature control to preserve platelet integrity during critical pre-transfusion periods.
The intelligent LCD controller ensures accurate temperature regulation (±0.5°C) with alarm functions and RS485 connectivity. Features power-failure recovery and includes USB data logging/printer ports for compliance records.
Triaxial drive technology with brushless DC motor delivers silent operation (≤40dB) at 20-120rpm, maintaining constant speed/torque without maintenance. The horizontal agitation platform accommodates multiple platelet bags with removable trays.
Stainless steel cavity with forced-air circulation (±0.3°C uniformity) and glass observation window. Meets blood bank sterilization requirements.
| Model | XYZ-0 | XYZ-1 | XYZ-2 |
| Workspace dimensions (mm) (H×W×D) | 740*590*400 | 990*590*400 | 1140*1090*400 |
| External dimensions (mm) (H×W×D) | 1340*670*630 | 1590*670*630 | 1740*1170*630 |
| Voltage(V) | 220 | ||
| Power(KW) | 1.2 | 1.5 | |
| Temperature(℃) | 15~35℃ | ||
| Accuracy(℃) | ±0.1℃ | ||
| Fluctuation(%) | ±0.5% | ||
| Number of layers/shelf dimensions | 10/W400*D300 | 15/W400*D300 | 40/W920*D300 |
| Number of Bags Accommodated | 20-30 | 40-45 | 80-120 |
| Oscillation Modes | Horizontal Reciprocating Motion | ||
| Amplitude and Oscillation Speed | 26mm 30-260r/m | ||
